RUCKUS R770 Pioneers the Wi-Fi 7 Evolution

High-Performance Tri-Radio Wi-Fi Indoor Access Point featuring 2x2:2, 4x4:4, and 2x2:2 configurations, with a maximum rate of 12.22 Gbps and integrated IoT capabilities.

Questions? Call us toll free @ 1-877-430-6240.
ruckus-r770-access-point-0l5a7207
ruckus-r770-access-point-0l5a7200
ruckus-r770-access-point-0l5a7210
ruckus-r770-access-point-0l5a7206
ruckus-r770-access-point-0l5a7202
ruckus-r770-access-point-0l5a7198

Ultra-fast, low latency wireless connections with enhanced capacity and efficiency

Wi-Fi 7 offers incredible speed, minimal latency, and increased capacity, providing outstanding user experiences and enabling a new generation of advanced connected devices and demanding applications. Looking for a solution for wireless devices to handle 8K video streaming, extended reality (XR) video conferencing, large-scale social gaming, and more? Wi-Fi 7 is the solution, and RUCKUS® brings it to fruition with the R770, the first enterprise-class access point supporting Wi-Fi 7 to enter the market.

RUCKUS Wi-Fi 7 is further improved by RUCKUS BeamFlex+ patented smart, directional antenna technology and RUCKUS AI, which optimize network performance.

icons-accelerateEnhanced Throughput & Capacity

  • RUCKUS BeamFlex+ across all three bands significantly enhances throughput and range.
  • 4K QAM and 320 MHz wide channels fully utilize the 6 GHz spectrum to provide exceptional throughput.
  • The 10 Gbps Ethernet port removes backhaul limitations.
  • AI-Driven Radio Resources Management streamlines support and boosts network performance.
  • Automated Frequency Coordination (AFC) increases signal strength and range by allowing the use of Standard Power (SP) mode at 6 GHz.

icons-adaptabilityAdaptive Resilience

  • Multi Link Operation (MLO) enhances reliability by sending data over several links to avoid disruptions.
  • Improved Wi-Fi resilience is achieved through AI-powered automated incident classification and suggested remediation actions.

icons-globalleaderReduced Latency

  • RUCKUS Wi-Fi 7 improvements, such as smart QoS mirroring, provide the precise latency required by applications.
  • The new Wi-Fi 7 QoS features enhance user experience across different situations.

icons-simplicityAdvanced Security Simplified

  • RUCKUS's unique DPSK3 integrates the strength of DPSK with WPA3, merging enhanced security with the convenience and adaptability of dynamic passphrases for network access protection.
  • Secure boot and TPM 2.0 provide hardware-level defense against malware and complex cyber threats.

933163-iot-networkingBuilt-in Modern IoT Stack

  • Integrated IoT radio supporting BLE and Zigbee, with a USB port for further expansion.
  • Comprehensive pre-integrated IoT solutions and ecosystems, ready for Matter and Thread*

    *Anticipated in a future software update.

Interested in Learning More? Get in Touch!

General Specifications

Antenna Patterns, per band 4000+
Antenna Gain Up to 4 dBi
BeamFlex Yes
ChannelFly Yes
Concurrent Users 1024
Controller Support RUCKUS OneTM | RUCKUS SmartZone | RUCKUS UnleashedTM | Standalone
Ethernet Ports 1 x 1 / 2.5 / 5 / 10 GbE | 1 x 1 GbE
IoT Support IoT OnBoard
Number of Radios Tri-Radio
PD-MRC Yes
PHY Rate at 2.4 GHz, maximum 689 Mb/s
PHY Rate at 5 GHz, maximum 5765 Mb/s
PHY Rate at 6 GHz, maximum 5765 Mb/s
Combined Max PHY Rate 12220 Mb/s
Radio Chains and Streams 2x2:2 (2.4 GHz) 4x4:4 (5 GHz) 2x2:2 (6 GHz)
Rx Sensitivity at 2.4 GHz -97 dBm
Rx Sensitivity at 5 GHz -100 dBm
Rx Sensitivity at 6 GHz -96 dBm
SmartMesh Yes
USB USB 2.0
Venue Type Education | Hospitality | MDU | Manufacturing | Office/Retail | Public Venue
Venue Sub-Type Convention Floor | Lecture Hall | Transit Stations | Venue Common Spaces
Wi-Fi Bands Supported 2.4 GHz | 5 GHz | 6 GHz
Wi-Fi Generation Wi-Fi 7
Wi-Fi Interface Standard IEEE 802.11a/b/g/n/ac/ax/be



Environmental Specifications

Operating Temperature 0 °C to +50 °C (+32 °F to +122 °F)
